- Complete 16' × 8' Garage Storage Wall
- Includes 128 Sq. Ft. of MKE Slatwall
- Supports Up to 450 lbs. per Sq. Ft.
- Premium, Textured Laminate Finishes
- Storage Accessories, Matching Trim & Installation Hardware Included
$2,999.00
✓
FREE Freight Included to the Contiguous U.S.
No additional shipping charge at checkout.
One Premium System, Configured for Your Garage
Build a complete 16' wide × 8' high MKE Slatwall garage storage wall without sourcing panels, trim, installation hardware, and accessories individually. Every system includes 128 sq. ft. of premium MKE Slatwall, matching installation components, and your choice of four coordinated storage packages.
Choose from eight textured laminate panel finishes and select the storage configuration that best fits your garage. The result is a complete, high-capacity storage wall with open slatwall space remaining for future accessories and changing storage needs.
Every System Includes
Slatwall
16' × 8' MKE Slatwall System
- (16) 96" W × 12" H panels
- 128 sq. ft. of wall coverage
- 4 cases of 8' MKE Slatwall
- Choose from 8 premium finishes
Finished Perimeter
Matching MKE Trim
- 6 × 96" J Trim
- 1 × 96" Division Trim
- Full 16' × 8' perimeter coverage
- Division Trim (optional at center seam)
Installation Hardware
Color-Matched Screws
- 4 installation screw packs
- 1-5/8" flathead screws
- Matched to your selected panel finish
- Installation hardware included
Why MKE Slatwall?
MKE Slatwall combines exceptional load capacity with a premium textured laminate surface, creating a garage storage wall designed to provide both serious storage capability and a more finished, higher-end appearance.
450 lbs.
Per Sq. Ft. Capacity
Supports up to 450 lbs. per square foot when properly installed.
Textured
Premium Laminate
A textured faux wood-grain laminate provides a refined alternative to conventional garage wall storage.
8 Color Options
Premium Finishes
Choose from eight panel finishes ranging from neutral textures to wood-inspired designs.
Flexible
Reconfigurable Storage
Move compatible hooks, baskets, shelves, and other accessories as your storage needs change.
Choose Your Storage Package
Each package is designed around a different style of garage organization. Select your preferred Storage Package using the options above. Each configuration provides substantial storage while preserving open slatwall space for future accessories.
Hook Storage
Tools & Equipment
Comprehensive hook and hanging storage for tools, lawn and garden equipment, sports gear, cords, and frequently used garage items.
24 straight, all-purpose & tool hooks
Specialty hooks for larger items
Magnetic bar, bins & utility storage
1 large & 2 medium baskets
View Full Package Contents
1 S-Hook
Bike Storage
Bikes & Cycling Gear
Purpose-built bike storage with four swiveling Steadyrack racks plus additional storage for helmets, apparel, and cycling gear.
4 Steadyrack bike racks
MKE Slatwall mounting brackets
8 additional storage hooks
1 medium & 2 small baskets
View Full Package Contents
Basket & Shelf Storage
Supplies & Equipment
Shelf and basket focused storage for bins, automotive supplies, detailing products, equipment, containers, and smaller garage items.
8 shelves in multiple styles & sizes
2 all-purpose shelf brackets
2 medium baskets
4 small baskets
View Full Package Contents
Mixed Storage
All-Purpose Storage
A balanced combination of hook, basket, and shelf storage for garages that need flexibility across a wide variety of items.
General-purpose & specialty hooks
6 storage baskets
Laminate, wire & angle shelving
Slot bins & specialty storage
View Full Package Contents
2 S-Hooks
✓ FREE Freight Included to the Contiguous U.S.
No additional shipping charge at checkout for standard qualifying destinations.
*Additional shipping restrictions may apply to certain locations.
Installation Overview
This system is designed to create a complete 16' wide × 8' high MKE Slatwall storage wall, providing 128 square feet of slatwall coverage.
The included panels install horizontally in eight 12" high rows. Each row uses two 8' panels to span the 16' wall, creating a vertical center seam. An 8' Division Trim piece is included and may be used at the center seam for a more finished appearance, depending on your aesthetic preference.
Included Installation Materials
- 4 cases of 8' MKE Slatwall panels — 16 panels total
- 6 × 8' J Trim
- 1 × 8' Division Trim — optional for finishing the center seam
- 4 packs of color-matching installation screws
16' × 8' Wall Layout
Install the panels horizontally across the wall in eight rows. Each row consists of two 8' panels meeting at the center of the 16' wall.
- Finished wall size: 16' W × 8' H
- Total coverage: 128 sq. ft.
- Eight horizontal panel rows
- Two 8' panels per row
- Align panel joints vertically at the center of the wall
- Division Trim may be installed over the center seam for a finished look, or omitted based on aesthetic preference
- Use J Trim around the outside perimeter for a finished edge
Before Installation
Confirm that the installation surface is structurally sound, locate the wall studs, and plan the finished position of the slatwall before beginning. Panels should be installed level and properly secured to the wall framing.
Because the completed system may support substantial loads, proper fastening and installation are essential. Follow MKE Slatwall installation requirements and use appropriate fastening methods for the wall construction.
Installing Accessories
After the slatwall is installed, hooks, baskets, shelves, and other compatible accessories can be positioned throughout the wall. Accessories can be moved later without permanently assigning a location, allowing the storage system to change as your garage storage needs evolve.
Tip: Before permanently positioning larger items such as bike racks or shelving, lay out the primary storage zones and leave sufficient clearance around vehicles, doors, work areas, and other garage features.
What is included with the MKE Slatwall 128 Sq. Ft. Premium Garage Storage System?
The system includes 128 square feet of MKE Slatwall panels, finishing trim, color-matching installation screws, and your choice of one of four coordinated storage packages. The included materials are designed to create a complete 16' wide × 8' high slatwall storage wall.
How much wall space does this system cover?
This system covers 128 square feet and is designed for a 16' wide × 8' high wall. It includes 16 individual 8' × 12" slatwall panels supplied in four cases.
What storage packages can I choose from?
Choose from four storage configurations: Hook Storage, Bike Storage, Basket & Shelf Storage, or Mixed Storage. Each package is designed for a different storage priority while leaving usable slatwall space available for repositioning accessories or adding more storage later.
What is included in each storage package?
Select a Storage Package above and use “View everything included” to see the exact hooks, baskets, shelves, bike racks, and other accessories included with that configuration.
What is included with the Bike Storage package?
The Bike Storage package includes four Steadyrack bike racks with MKE Slatwall brackets, along with additional hooks and baskets included in the MKE Steadyrack bundle. You can choose between Steadyrack Classic / Road Bike or Mountain Bike racks when configuring the system.
Can I move the accessories after they are installed?
Yes. One of the primary advantages of slatwall storage is flexibility. Compatible hooks, baskets, shelves, and other accessories can be repositioned along the slatwall as your storage needs change.
Can I add more accessories later?
Yes. The storage packages are intentionally designed to provide useful storage without overcrowding the wall. Additional compatible hooks, baskets, shelves, bins, and specialty accessories can be added later.
Are accessories from other slatwall brands compatible with MKE Slatwall?
MKE Slatwall uses a standard 3" on-center slatwall profile and is compatible with many standard slatwall accessories, including compatible accessories offered by other brands. Some proprietary slatwall systems and accessories may use different mounting profiles, so compatibility should be confirmed before purchasing accessories designed for a proprietary system.
How much weight can MKE Slatwall support?
MKE Slatwall can support up to 450 lbs. per square foot when properly installed. Actual load capacity depends on proper installation, wall construction, fastening, accessory selection, and how the load is distributed.
What finishes are available?
The system is available in eight premium textured laminate finishes. Select your preferred Panel Color/Finish above to configure the system.
What installation materials are included?
The system includes four cases of 8' MKE Slatwall panels, six 8' J Trim pieces, one 8' Division Trim piece, and four packs of color-matching installation screws.
Do I have to use the Division Trim?
No. The included Division Trim is optional. It can be installed over the vertical center seam between the two 8' panel sections for a more finished appearance, or omitted based on your aesthetic preference.
How are the panels arranged on a 16' × 8' wall?
The panels install horizontally in eight 12" high rows. Each row uses two 8' panels, with the panel joints aligned vertically at the center of the 16' wall.
Is freight shipping included?
Yes. Freight shipping is included within the contiguous United States, so there is no additional shipping charge at checkout for standard qualifying destinations. Additional shipping restrictions may apply to certain locations.
Can I use this system on a wall that is not exactly 16' × 8'?
The included panel and trim quantities are configured specifically for a 16' wide × 8' high installation. MKE Slatwall panels can be cut during installation, but changing the wall dimensions may change the amount of trim required and may result in unused panel material. For a different wall size, contact us before ordering so we can help determine the appropriate material quantities.
